IEC 60079: Explosive atmosphere safety. Covers intrinsic safety, flameproof, increased safety for batteries in gas/dust hazards; ensures no ignition source under fault conditions.
UL 2580: North American safety standard for large‑capacity special robot batteries; verifies structural integrity under extreme abuse.
IEC 62133: General safety for Li‑ion batteries. Includes overcharge, short circuit, vibration, thermal cycling – baseline safety validation.
UN 38.3: Mandatory transport safety. Eight tests: thermal cycling, vibration, shock, short circuit, overcharge, etc. Required for shipment.
The CE-6000 series offers performance testing and safety validation for special-function robot batteries, with precise verification and intelligent data analysis under diverse operating conditions.
1. Multi-range design supports testing from standby to high-power discharge. ±0.02% of F.S. / ±0.05% of F.S. accuracy and 24-bit resolution ensure precise capacity and runtime measurement, eliminating performance overstatement.
2. Simulates real usage with high-rate charge/discharge and long-term cycle tests (up to 65,535 cycles). Custom steps and cycle nesting assess capacity fade and reliability under shallow or deep cycling.
3. Integrates with AUX channels to monitor surface temperature and internal resistance. Syncs thermal and electrical data to evaluate battery health and safety.
Current Accuracy: ±0.05% F.S.
Voltage Accuracy: ±0.02% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤6ms
Current Response Time: ≤3ms
Minimum Pulse Width: 100ms
Feedback Efficiency (Max): 90%
Voltage & Current Accuracy: ±0.02% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤20ms
Current Response Time: ≤10ms
Minimum Pulse Width: 50ms
Feedback Efficiency (Max): 96%
The All-in-One series validates special-function robot batteries at various temperatures, simulates extreme environments, simplifies setup, saves space, and boosts multi-device coordination.
1. Wide temperature range: Covers -70℃ to +150℃, verifying product performance and charge acceptance under extreme conditions.
2. Precise data synchronization: BTS software automatically synchronizes charge/discharge data with temperature data in real-time, ensuring accurate analysis and consistent assessment of temperature's impact on battery performance.
Volume: 200L
Space for Test System: 6U
Temperature Fluctuation: ≤0.9℉ (0.5℃)
Temperature Deviation: ±3.6℉ (±2℃)
Heating Time: 68°F ~ 302°F≤60min
(20℃ ~ 150℃≤60min)
Cooling Time: 68°F ~ -40°F≤60min
(20℃ ~ -40℃≤60min)
Volume: 200L*2
Space for Test System: 12U
Temperature Fluctuation: ≤0.9℉ (0.5℃)
Temperature Deviation: ±3.6℉ (±2℃)
Heating Time: 68°F ~ 302°F≤60min
(20℃ ~ 150℃≤60min)
Cooling Time: 68°F ~ -40°F≤60min
(20℃ ~ -40℃≤60min)
Volume: 400L*2
Space for Test System: 32U
Temperature Fluctuation: ≤0.9℉ (0.5℃)
Temperature Deviation: ±3.6℉ (±2℃)
Heating Time: 68°F ~ 302°F≤60min
(20℃ ~ 150℃≤60min)
Cooling Time: 68°F ~ -40°F≤60min
(20℃ ~ -40℃≤60min)
Volume: 400L*2
Space for Test System: 32U
Temperature Fluctuation: ≤0.9℉ (0.5℃)
Temperature Deviation: ±3.6℉ (±2℃)
Heating Time: 68°F ~ 302°F≤60min
(20℃ ~ 150℃≤60min)
Cooling Time: 68°F ~ -40°F≤60min
(20℃ ~ -40℃≤60min)
* This product model has been updated.
