CE-6000 Series

CE-6000 Series

- For EVs, communication base stations, and energy storage systems.

The CE-6000 series delivers comprehensive testing capabilities—including pulse, simulation, EOL, and BMS testing—enabling full performance and safety evaluation from Cells to Packs.

· Upgraded Cell Testing System delivers ±0.02% F.S. current accuracy.

· 3000V ultra-high voltage for storage Packs, high-voltage Battery Clusters, and Power Conversion System (PCS) testing.

· EOL (End-of-Line ) Testing System for performance and safety tests.

· BMS Testing System for comprehensive verifies BMS performance.

CE-6000 Cell Testing System NEWARE Battery Testing Solutions

CE-6000 Cell Testing System

NEWARE CE-6000: Specialized battery tester for SOC, DOO, EV battery, solar panel battery, electric car battery. Reliable test equipment for power cells.

Voltage & Current Accuracy: ±0.05% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤6ms
Current Response Time: ≤3ms
Minimum Pulse Width: 100ms
Feedback Efficiency (Max): 75%

For Cell Testing in uncompromising quality. It is designed for testing electric vehicle power cells, equipped with various testing functions such as simulation of operating conditions and DCIR (Direct Current Internal Resistance) testing.

CE-6000-Pro Cell Testing System NEWARE Battery Testing Solutions

CE-6000-Pro Cell Testing System

Upgraded power cell testing with enhanced voltage and current accuracy, setting a new benchmark for testing standards. Delivering an entirely new testing experience for power battery R&D and manufacturing.

Voltage & Current Accuracy: ±0.02% F.S.
High-Frequency Sampling: 200Hz
Current Conversion Time: ≤2ms
Current Response Time: ≤1ms
Minimum Pulse Width: 10ms
Feedback Efficiency (Max): 75%

Performance of the Power Cell Testing System has been comprehensively upgraded, setting a new benchmark for testing standards. Delivering an entirely new testing experience for power battery R&D and manufacturing.

· Ultimate Accuracy : ±0.02% F.S.

· Ultra-Fast Response : ≤1ms

· High-Frequency Sampling: 200Hz

CD-6006A-5V1200A-PS-H NEWARE Battery Testing Solutions

CD-6006A-5V1200A-PS-H

Intelligent Current Superposition Cell Testing System

For the R&D of power cell testing, dynamic current shunt protection ensures testing safety, and 750V DC bus technology improves testing efficiency and reduces energy consumption.

Voltage Accuracy: ±0.02% F.S.
Current Accuracy: ±0.05% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤6ms
Current Response Time: ≤3ms
Minimum Pulse Width: 50ms

N+1 channel scheme and 750V DC bus improve energy utilization.

The table shows multiple ranges:

Range 1: 75A / Range 2: 150A / Range 3: 300A / Range 4: 600A (with superimposed shared channels, Range 4 can reach 1200A)

CE-6000 Module Testing System NEWARE Battery Testing Solutions

CE-6000 Module Testing System

NEWARE battery tester as battery pack, fuel cell, Electric vehicle battery, Electric car battery, Power cell, Battery Module, Provide efficient and accurate testing, such as SOC,DOO,PCIR test.

Current Accuracy: ±0.05% F.S.
Voltage Accuracy: ±0.02% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤6ms
Current Response Time: ≤3ms
Minimum Pulse Width: 100ms
Feedback Efficiency (Max): 90%

CE-6000 Module Testing System is designed for high-power-density battery module testing, provide efficient and accurate testing, such as SOC, DOO, PCIR test.

CE-6000 Pack Testing System NEWARE Battery Testing Solutions

CE-6000 Pack Testing System

NEWARE battery tester for EV battery, solar panel battery,pack battery, and power cells. Perform SOC, DOO, and DCIR tests on electric car batteries and more.

Voltage Accuracy: ±0.02% F.S.
Current Accuracy: ±0.05% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤10ms
Current Response Time: ≤5ms
Minimum Pulse Width: 100ms
Feedback Efficiency (Max): 94%

CE-6000 Pack Testing System is designed for testing electric vehicle battery packs, equipped with various testing functions such as simulation of operating conditions and DCIR testing, which is crucial for in-depth research and evaluation of the electrical performance of battery packs.

CE-6002-1500V200A NEWARE Battery Testing Solutions

CE-6002-1500V200A

1500V Ultra-High Voltage Battery Cluster Solution

Ultra-high voltage module machine for Energy Storage Pack testing, ultra-high voltage Energy Storage Battery Cluster testing, and high voltage DC Source Simulation testing (PCS Testing).

Voltage & Current Accuracy: ±0.02% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤20ms
Current Response Time: ≤10ms
Minimum Pulse Width: 50ms
Feedback Efficiency (Max): 96%

Ultra-high voltage module machine for Energy Storage Pack testing, ultra-high voltage Energy Storage Battery Cluster testing, and high voltage DC Source Simulation testing (PCS Testing).

CE-6001n-3000V200A NEWARE Battery Testing Solutions

CE-6001n-3000V200A

3000V Ultra-high Voltage Battery Testing System

Ultra-high voltage module machine for Energy Storage Pack testing, ultra-high voltage Energy Storage Battery Cluster testing, and high voltage DC Source Simulation testing (PCS Testing).

Voltage & Current Accuracy: ±0.02% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤20ms
Current Response Time: ≤10ms
Minimum Pulse Width: 50ms
Feedback Efficiency (Max): 96%

Ultra-high voltage module machine for Energy Storage Pack testing, ultra-high voltage Energy Storage Battery Cluster testing, and high voltage DC Source Simulation testing (PCS Testing).

CE-6002-200V200A-EOL NEWARE Battery Testing Solutions

CE-6002-200V200A-EOL

EOL Battery Testing System

A one-stop high-precision platform for safety inspection and performance validation of power batteries, covering safety compliance testing, BMS integration, charge/discharge cycling, and data traceability.

Voltage Accuracy: ±0.02% F.S.
Current Accuracy: ±0.05% F.S.
Recording Frequency: 100Hz
Current Conversion Time: ≤6ms
Current Response Time: ≤3ms
Minimum Pulse Width: 100ms

Lithium battery pack End-of-Line (EOL) testing. A one-stop high-precision platform for safety inspection and performance validation of power batteries, covering safety compliance testing, BMS integration, charge/discharge cycling, and data traceability.

CE-6S-BMS-24S300A NEWARE Battery Testing Solutions

CE-6S-BMS-24S300A

BMS Testing System

Verifies the reliability and safety of battery management systems in all aspects.

Current Accuracy: ±0.05% F.S.
Voltage Range: 0-1500V
Range of Adjustable: 2Ω-1MΩ
Number of Channels: 24CH
Communication Module: CAN, RS232, IIC, SMBUS, RS485

BMS R&D verification ensures safety and reliability.

· Battery module/cell simulation .

· BMS balancing, insulation and SOC estimation algorithm verification.

· BMS charge/discharge and high-voltage safety testing .

· In-vehicle condition-based communication and function verification.

Powerful programmability. Meet diverse testing needs.

Comprehensive equipment functionality, compatible with both charging and discharging, and adaptable to various BMS systems.

DBC configuration

CC & CV charge/discharge test

20ms pulse width

Driving simulation

Communication can be achieved by editing the DBC protocol files corresponding to different protocols of batteries.

CC charging or discharging until the voltage reaches the specified value, and then seamlessly switching to CV mode for battery compensation which is smooth without any spikes.

Testing the performance of the battery under fast changes in current/power.

Supports up to 1 million lines of changing data.
