For use in pouch cell and power battery cell charging and discharging, capacitance voltage, and formation and capacity grading tests.
* This product model has been updated. For details, please refer to Pouch Cell Clamps, or consult a sales expert.
Features
Tech Specs
The pouch cell positive fixture, designed for 1500A power batteries, is used in combination with the P103-12-TZ-R-LS-1500A-. It has a high current carrying capacity, precisely fixes the battery, ensures uniform pressure between the electrode and the contact sheet, enhances the battery's conductivity and structural stability, and ensures stable and reliable testing.
| Equipment name | 1500A Pouch Cell Positive Clamp |
|---|---|
| Model | P103-12-TZ-R-LS-1500A- |
| Current | 1500A |
| External Size: | 5.5"×5.9"×1.6" (141×150×40mm) |
